AHD/CVI/TVI 720P/1080P (2MP) Video Balun for CC Camera

Original price was: ৳ 275.00.Current price is: ৳ 180.00.

  • Model: Video Balun for CC Camera
  • Video Baluns connector
  • Use For – Camera or DVR
  • Transmission signal: 1 channel
  • Coaxial video connector: BNC-M

» ঢাকার বাহিরের অর্ডারের ক্ষেত্রে পণ্যের মূল্যের ১৫% বিকাশ মার্চেন্ট নাম্বারে অগ্রিম Make Payment করে অর্ডার নিশ্চিত করতে হবে। অন্যথায় অর্ডার বাতিল হয়ে যাবে।

  Ask a Question



Basic Information
Others Transmission signal: 1 channel
Transmission distance: AHD/CVI:400m(max) / TVI: 200m(max)
Category Type: UTP CAT5/5E/6
Coaxial video connector: BNC-M
Twisted-pair video connector: Screw-terminal
Compatible Format: AHD / HDCVI /HDTVI/CVBS
Resolution: 720P/960P/1080P/3MP/4MP/5MP/8MP
Anti-interference: >60dB
ESD: 1a contact discharge electricity level 3 / 1b air discharge electricity level 3 /
Per: IEC61000-4-5, Coaxial cable
connector: 2KV(common-code) Per: IEC61000-4-5
UTP Cable Connector: 2KV(different code)
4KV(common-code)Per: IEC61000-4-5
BNC male: 75 Ohms
UTP: 100 Ohms
Manufacturing Warranty
Warranty No Warranty


AHD/CVI/TVI 720P/1080P (2MP) Video Balun for CC Camera

The AHD/CVI/TVI 720P/1080P (2MP) Video Balun is a device that functions as a connector for cameras or DVRs. This video balun comes in black and can transmit a single channel of the video signal. It is compatible with various formats such as AHD, HDCVI, HDTVI, and CVBS, and can support a resolution range of 720P, 960P, 1080P, 3MP, 4MP, 5MP, and 8MP. This device is designed to provide excellent anti-interference capability with over 60 dB. It has a coaxial video connector with BNC-M and a twisted-pair video connector with a screw terminal. The transmission distance for AHD/CVI is 400m (max) while for TVI it is 200m (max). This video balun is compatible with UTP CAT5/5E/6 category-type cables. It has a coaxial cable connector with 2KV (common code) and a UTP cable connector with 2KV (different code) or 4KV (common code), as per the IEC61000-4-5 standards. The BNC male connector has a resistance of 75 Ohms, while the UTP connector has a resistance of 100 Ohms.
